Auto-focus head, flexible piercing technique, support auto change focal position in piercing, suitable for thick metal plate processing; Suitable for sheet and tube processing, software can help to Auto Find Tube Center in Production, and enjoy Active Control at Corner Cutting; Support offset tube center error in production to improve through holes cutting precision;

It can cut carbon steel plate, stainless steel plate, aluminum plate, especially ultra-high-strength steel plate which is very difficult to stamp with a punch press;The machine adopts high-precision leveling machine, high-precision feeding and cutting system, advanced automatic palletizing system, etc., which can adapt to the production of blank parts of various metal materials;

The light source uses Germany IPG laser, with high photoelectric conversion efficiency and low power loss; multi-modular design ensures uninterrupted work; laser response speed is fast and the effect is good; small size, less land occupation, saving space; Adopt gantry double-sided drive device, imported servo motor, equipped with high-precision reducer and rack and pinion, with high transmission dynamic efficiency and good stability; Automatic parameter selection, embedded design of all cutting parameters, automatic system setting , less manual intervention, simple operation; Automatic lubricating device, set working time and guide rail travel distance, automatic oil lubrication guide rail, long service life; Equipped with a "dual temperature and dual control" patented water chiller, it not only ensures the cooling equivalent of the equipment, but also maximizes the save energy and electricity to the maximum, and further reduce customer operating costs.

Autofocus laser head realizes 80% less time required for piercing than normal head, which is especially suitable for thick metal sheet and highly reflective materials; Applying High-quality laser achieves higher than 30% photoelectric conversion efficiency, and the machine will blow air while cutting, which can greatly lower the cost and improve the efficiency;Variable functions available, such as scanning cutting, blasting perforation, automatic edge finding and etc.

FRIENDESS FSCUT3000S numerical control system based on Windows system, special platform of laser tube cutter, integrated with special function module of laser cutting control, powerful function, friendly interface, simple operation； The linear positioning speed can reach 100m/min, and the rotary positioning speed can reach 120m/min； Automatic bundle feeding function (optional) to reduce the number of operators and improve the processing efficiency.

Process task list function. Double drive gantry structure. Remote diagnostic function. Automatic hydraulic lifting exchange system (optional). CCD edge finding/positioning function (optional).

Developed variable frequency cutting zoom perforation technology ensures high-efficiency and high-quality processing of plates of different thicknesses and materials. All process parameters can be fully digitally controlled, which greatly reduces manual intervention and is intelligent and simple;Hydraulic lifting platform, stable and efficient cutting; The key components are all German accessories, high-end configuration, good stability and durability;

The machine tool adopts gantry type double rack and pinion, double servo motor drive, high torque and high inertia output, which effectively improves the production efficiency of the equipment; The whole machine adopts a fully enclosed outer protection design , which can effectively protect the work safety of equipment operators; Classic applications - laser cutting of metal cabinets, laser cutting of stainless steel thick plates, etc.

Casting frame structure,high accuracy and stability, effectively eliminate the vibration generated during high-speed cutting. Dual lead screws, synchronized driving system, high-speed arc cutting function. Automatic lubrication system, maintenance-free transmission system. Programmable power, frequency and speed control to achieve good cutting quality.

Enclosed protection cover with safety interlock design,simple for operation; Pipe cutting is sealed inside of the machine protection housing, reduce accidental injury; Optional different types of jaws can realize the cutting processing of different profiles,such as: angle steel, channel steel, I-beam; Adopts gantry structure,guarantee the machine tool long term accuracy and stability; Equipped with a special workbench for pipe cutting to assist the processing and blanking of long pipe workpieces; Optional laser pipe cutting machine dedicated plat-form,the plate and tube can be switched at any time,front butt,and the side operation is close; Driven by high-precision servo motor, equipped with high-precision trans-mission mechanism, high installation accuracy, large transmission torque,small transmission error, and good dynamic characteristics; The pipe cutting mechanism feeds 3 meter at a time. After the cutting is completed, it is fed and processed one by one, which can complete the cutting process of raw material pipes of more than 6 meters.

Zero tailing tube cutting machine adopt zero waste chuck design scheme, save the waste of pipe; Top-mounted warehouse,50% floor area saved; Two station automatic feeding at the same time,Auto-adjusting four-jaw roller chuck; · Efficiency increased by 81% ,The floor area is reduced by 23%; Automatic tube loading mecheanism, Two stations can be independently and automatically loading tube; Automatic tube clamping and centering no need to manually adjust the clamping position; Automatic and convenient material receiving design; One-person operate multi- machine.

Large gantry milling, guarantee the machine tool long term accuracy and stability; Support offset tube center error in production to improve through holes cutting precision; Eccentric wheel bracket: effectively correct the pipe and increase accuracy; Equipped with automatic pipe head alignment system, no manual intervention and adjustment required; The cutting head directly locates the center of the pipe, high efficiency performance.

Single bed fiber laser cutting machine series models adopt professional laser cutting software, which is easy to learn. According to different process applications, there are four cutting working of 1500*3000mm, 1500*4000mm, 1500*6000mm, and 2000*4000mm to choose from.

Fiber laser cutting machine with shuttle table series, working area range from 1500*3000mm to 8000*2500mm, bigger size customization available. Metal material cutting range from 1mm to 40mm thickness like stainless steel, carbon steel, aluminum, copper cutting , widely used for lighting, household appliances, furniture manufacturing, metal kitchen cabinet, shipbuilding, mechanical manufacturing etc. HystoRe storage system optional

Three-chuck fiber laser tube cutting machine; material loading and unloading system ; support high-speed laser cutting processing of round pipes, square pipes, special-shaped pipes, angle steel, I-beam, channel steel, etc.
