Fiber Laser Marking Machine MF-E-A

Introduction

Inquiry

Parameter

Modle

MF-E-A standard edition
Features

300*300mm marking table, uniform installing holes, suitable for different workpieces positioning.
Laser power(W)

20/30/50/70/100/120
Working area(mm)

70 x 70 / 110 x 110 / 175 x 175 / 200 x 200/300 x 300/400 x 400
Lifting height(mm)

500(optional 800)
Minimum line width

0.03mm
Minimum character

0.2mm
Graphic format supported

BMP、PLT、AI、DXF etc.
Supply voltage

AC220V±10%,50Hz/60Hz
Machine dimension

600mm×750mm×1270mm
Weight

80Kg (Estimation)
Work environment

Clean, less dust,Temp:10~35°C, Humidity:5~85%
Total power

1Kw

High quality fiber generator, good quality spot, optical power density uniform, stable output optical power, meets the application demand of mainstream market;
Han's Yueming self-developed digital high-speed galvanometer scanner, small size, high speed and excellent stability; the performance reaches the international advanced level;
Powerful control system, optimizes the processing data according to various application, supports multi language switch, and up to 256 color layer management functions, meets the application requirements of most industries;
Die-casting mold manufacturing lifting frame, stable structure, built-in linear guide, simple design.
